Supply air 18 inch front to back and 7-9/16 inches wide - Return air 22-1/2 inches front to back and 15-7/8 inches wide - No filter rack

Versatile 3 way convertible design for upflow, horizontal left and horizontal right applications - Factory installed high efficiency indoor coil

Sturdy construction with 1 inch of reinforced foil faced jacket insulation for excellent thermal and sound insulation

Four leg blower motor mount - Tab lock blower housing with controls, motor and blower use a slide out design for service and maintenance convenience

Interface board with dip switches conveniently located in the blower compartment allows for precise, field selectable airflow - Coils are constructed of aluminum fins bonded to internally grooved copper tubing

Molded polymer corrosion resistant condensate drain pan is provided on all indoor coils - Supply and return duct flanges provided as standard on air handler cabinet

Provisions for field electrical and other connections available from either side of the air handler cabinet

Connection point for high and low voltage wiring is inside the air handler cabinet

Concentric knockouts are provided for power connection to cabinet - Installer may pull desired hole size up to 2 inches for 1-1/2 inch conduit

Front refrigerant and drain connections
